Apache Pinot 0.12: Consumer Record Lag

The Apache Pinot community recently released version 0.12.0 , which has lots of goodies for you to play with. I’ve been exploring and writing about those features in a series of blog posts.

This post will explore a new API endpoint that lets you check how much Pinot is lagging when ingesting from Apache Kafka.

Why do we need this?

A common question in the Pinot community is how to work out the consumption status of real-time tables.

This was a tricky one to answer, but Pinot 0.12 sees the addition of a new API that lets us see exactly what’s going on.

Worked Example

Let’s have a look at how it works with help from a worked example.

First, we’re going to create a Kafka topic with 5 partitions:

docker exec -it kafka-lag-blog kafka-topics.sh  --bootstrap-server localhost:9092
--partitions 5
--topic events
--create

Copy

We’re going to populate this topic with data from a data generator, which is shown below:

import datetime, uuid, random, json, click, time
@click.command()
@click.option('--sleep', default=0.0, help='Sleep between each message')
def generate(sleep):
 while True:
 ts = datetime.datetime.now().strftime("%Y-%m-%dT%H:%M:%S.%fZ")
 id = str(uuid.uuid4())
 count = random.randint(0, 1000)
 print(json.dumps({"tsString": ts, "uuid": id, "count": count}))
 time.sleep(sleep)

if __name__ == '__main__':
 generate()

Copy

We can see an example of the messages generated by this script by running the following:

python datagen.py –sleep 0.01 2>/dev/null | head -n3 | jq -c

You should see something like this:

{"tsString":"2023-03-17T12:10:03.854680Z","uuid":"f3b7b5d3-b352-4cfb-a5e3-527f2c663143","count":690} {"tsString":"2023-03-17T12:10:03.864815Z","uuid":"eac57622-4b58-4456-bb38-96d1ef5a1ed5","count":522}
{"tsString":"2023-03-17T12:10:03.875723Z","uuid":"65926a80-208a-408b-90d0-36cf74c8923a","count":154}

Copy

So far, so good. Let’s now ingest this data into Kafka:

python datagen.py --sleep 0.01 2>/dev/null | jq -cr --arg sep ø '[.uuid, tostring] | join($sep)' |
kcat -P -b localhost:9092 -t events -Kø

Copy

Next we’re going to create a Pinot schema and table. First, the schema config:

{  "schemaName": "events",
 "dimensionFieldSpecs": [{"name": "uuid", "dataType": "STRING"}],
 "metricFieldSpecs": [{"name": "count", "dataType": "INT"}],
 "dateTimeFieldSpecs": [
 {
 "name": "ts",
 "dataType": "TIMESTAMP",
 "format": "1:MILLISECONDS:EPOCH",
 "granularity": "1:MILLISECONDS"
 }
 ]
 }

Copy

And now, the table config:

{  "tableName": "events",
 "tableType": "REALTIME",
 "segmentsConfig": {
 "timeColumnName": "ts",
 "schemaName": "events",
 "replication": "1",
 "replicasPerPartition": "1"
 },
 "tableIndexConfig": {
 "loadMode": "MMAP",
 "streamConfigs": {
 "streamType": "kafka",
 "stream.kafka.topic.name": "events",
 "stream.kafka.broker.list": "kafka-lag-blog:9093",
 "stream.kafka.consumer.type": "lowlevel",
 "stream.kafka.consumer.prop.auto.offset.reset": "smallest",
 "stream.kafka.consumer.factory.class.name": "org.apache.pinot.plugin.stream.kafka20.KafkaConsumerFactory",
 "stream.kafka.decoder.class.name": "org.apache.pinot.plugin.stream.kafka.KafkaJSONMessageDecoder",
 "realtime.segment.flush.threshold.rows": "10000000"
 }
 },
 "ingestionConfig": {
 "transformConfigs": [
 {
 "columnName": "ts",
 "transformFunction": "FromDateTime(tsString, 'YYYY-MM-dd''T''HH:mm:ss.SSSSSS''Z''')"
 }
 ]
 },
 "tenants": {},
 "metadata": {}
 }

Copy

We can create both the table and schema using the AddTable command:

docker run   --network lag_blog
 -v $PWD/config:/config
 apachepinot/pinot:0.12.0-arm64 AddTable
 -schemaFile /config/schema.json
 -tableConfigFile /config/table.json
 -controllerHost "pinot-controller-lag-blog"
 -exec

Copy

Now let’s call the /consumingSegmentsInfo endpoint to see what’s going on:

curl “http://localhost:9000/tables/events/consumingSegmentsInfo” 2>/dev/null | jq

The output of calling this end point is shown below:

{  "_segmentToConsumingInfoMap": {
 "events__0__0__20230317T1133Z": [
 {
 "serverName": "Server_172.29.0.4_8098",
 "consumerState": "CONSUMING",
 "lastConsumedTimestamp": 1679052823350,
 "partitionToOffsetMap": {
 "0": "969"
 },
 "partitionOffsetInfo": {
 "currentOffsetsMap": {
 "0": "969"
 },
 "latestUpstreamOffsetMap": {
 "0": "969"
 },
 "recordsLagMap": {
 "0": "0"
 },
 "availabilityLagMsMap": {
 "0": "26"
 }
 }
 }
 ],
…
}

Copy

If we look under partitionOffsetInfo , we can see what’s going on:

currentOffsetsMap is Pinot’s current offset
latestUpstreamOffsetMap is Kafka’s offset
recordsLagMap is the record lag
availabilityLagMsMap is the time lag

This output is a bit unwieldy, so let’s create a bash function to tidy up the output into something that’s easier to consume:

function consuming_info() {  curl "http://localhost:9000/tables/events/consumingSegmentsInfo" 2>/dev/null |
 jq -rc '[._segmentToConsumingInfoMap | keys[] as $k | (.[$k] | .[] | {
 segment: $k,
 kafka: (.partitionOffsetInfo.currentOffsetsMap | keys[] as $k | (.[$k])),
 pinot: (.partitionOffsetInfo.latestUpstreamOffsetMap | keys[] as $k | (.[$k])),
 recordLag: (.partitionOffsetInfo.recordsLagMap | keys[] as $k | (.[$k])),
 timeLagMs: (.partitionOffsetInfo.availabilityLagMsMap | keys[] as $k | (.[$k]))
})] | (.[0] |keys_unsorted | @tsv), (.[] |map(.) |@tsv)' | column -t
 printf "n"

}

Copy

Let’s call the function:

consuming_info

We’ll see the following output:

Consumer record lag output

Now let’s put it in a script and call the watch command so that it will be refreshed every couple of seconds:

!#/bin/bash
function consuming_info() {
 curl "http://localhost:9000/tables/events/consumingSegmentsInfo" 2>/dev/null |
 jq -rc '[._segmentToConsumingInfoMap | keys[] as $k | (.[$k] | .[] | {
 segment: $k,
 kafka: (.partitionOffsetInfo.currentOffsetsMap | keys[] as $k | (.[$k])),
 pinot: (.partitionOffsetInfo.latestUpstreamOffsetMap | keys[] as $k | (.[$k])),
 recordLag: (.partitionOffsetInfo.recordsLagMap | keys[] as $k | (.[$k])),
 timeLagMs: (.partitionOffsetInfo.availabilityLagMsMap | keys[] as $k | (.[$k]))
})] | (.[0] |keys_unsorted | @tsv), (.[] |map(.) |@tsv)' | column -t
 printf "n"
}

export -f consuming_info
watch bash -c consuming_info

Copy

Give permissions to run it as a script:

chmod u+x watch_consuming_info.sh

And finally, run it:

./watch_consuming_info.sh

This will print out a new table every two seconds. Let’s now make things more interesting by removing the sleep from our ingestion command:

python datagen.py 2>/dev/null | jq -cr --arg sep ø '[.uuid, tostring] | join($sep)' |
kcat -P -b localhost:9092 -t events -Kø

Copy

And now if we look at the watch output:

Apache Pinot Consumer Record Lag

We get some transitory lag, but it generally goes away by the next time the command is run.

Summary

I love this feature, and it solves a problem I’ve struggled with when using my datasets. I hope you’ll find it just as useful.

Give it a try, and let us know how you get on. If you have any questions about this feature, feel free to join us on Slack , where we’ll be happy to help you out.
